4 foot 4 Lamp T5 Fluorescent Fixture
Quick Connect Power Cord Receptacle
7 different power cords available for use with the quick connect power cord receptacle.
Universal Voltage 120-277 Volt Ballast
Less noise than metal halide and no waiting for cool down and restrike. The high lumen ballast has a -20º F start and a NEMA ballast disconnect. 480 Volt is available.
Mounting
Fixture is designed for gripple aircraft cable installations.
Quality Cam-Lock Lampholders
Prevents the lamp from slipping out.
Optional
Optional Wrap lens is available.
Ballast Channel
The ballast channel has sufficent knockouts for electrical supply and has tool-free quarter-turn ballast access.
Solid Reflector Body
The reflector is preattached to the endplates with screws and provides added rigidity.
Venting And Uplighting
Venting holes allow heat to escape and keeps dust from collecting on the lamps or reflector. 3% uplighting allows for ceiling and duct work maintenance.
Lamp Retaining Rail
Allows for ease of lamp installation and replacement.
Warranty
The fixture and ballasts are warrantied for 5 years and the lamps are warrantied for 2 years.
95% Specular Reflector
The CNC formed .020" specular aluminum reflector has 5 mirrored angles per lamp for unsurpassed lamp imaging. The reflector produces even lighting patterns to eliminate shadows and hot spots.
Manufactured from US Steel and Assembled in USA
|
|
