Minimum Clearances: Direct contact allowed; no clearances are required
Ceiling Thickness: Accepts 5/8"-1-3/8" to accommodate various ceiling thicknesses
Lamp Position: Socket clips directly to back of trim for perfect 90º vertical alignment of lamp socket. Socket is automatically positioned for optimum performance and lamp position consistency when socket is installed on trim or reflector.
Installation: Bar hangers are adjustable from 13-3/4" to 24-1/2" with captive nails and can be repositioned 90º
Junction Box: Junction box is listed for through branch circuit wiring and contains seven 1/2" knockouts and four Romex® with strain relief
Electrical: Quick Connector provided
Maximum Wattage: 75W (actual wattage varies with trim)
Dimensions:
Length: 10-1/2"
Width: 7-1/4"
Depth: 7-1/2"
Ceiling Opening: 5-3/8"
Spec Sheet: NHIC-501QAT_spec.pdf
