Extrusion
0.030 die cast aluminum construction with 0.045 PVC insulators holding 12-gauge flat
copper conductor wiring. Polarity groove is located on face of track to indicate location of
grounding conductor.
Electrical
Voltage: 120V 60Hz / 20A Max.
Maximum Wattage: 2400 watts
Polarity Groove
Each track section includes a groove on the surface of the extrusion. This groove must be
continuous throughout the track run. Track heads also have a polarity arrow, which must
coincide with the track's polarity groove.
End Cap
Two dead end caps with screws are included with each track section.
Mounting
The track may be surface, stem, or cable mounted (see page 5). All lengths can be field cut.
Surface mounting hardware included with each track section.
Compatibility
Nora track heads are compatible with Halo or any other brands configured to Halo 3 wire
track configuration.
Note: Wands and monopoint canopies are generally not compatible with other
manufacturers.
Dimming
Nora track may be dimmed with any approved incandescent, magnetic low voltage, or
electronic low voltage controls, depending on the track fixtures being used. Do not attempt
to use 3-way or multi-phase neutral if dimming.
Spec Sheet:
NT-301S Spec Sheet
