6 Watts
223 Lumens
2700K
(Soft White)
80 CRI
Emits no UV light
Wet Locations
IP66 Rated
Wet Locations
Not Dimmable
Minimum Temp
-34°F
12V AC
5 Year Warranty
Product Description
RAB 6 watt 2700K 12 volt Fern LED floodlight with a verde green finish.
Product Features
IP66 Rating
Ingress Protection rating of IP66 for dust and water.
Wet Location Rated
Suitable for wet locations. Suitable for mounting within 4 feet of the ground.
Environmentally Friendly
Mercury and UV free. RoHS-compliant components.
IESNA LM-79 & LM-80 Testing
This luminaire has been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
80 CRI
Ideal for general lighting applications.
Specifications
| Housing Material | Precision die-cast aluminum housing |
| Finish | Verde Green |
| Gaskets | High-temperature EPDM foam silicone |
| Includes | 8" ground spike |
| Lens | Solite glass lens |
| Mounting |
1 Swivel arm with 1/2" NPS threads. Mounts to included sturdy plastic spike for ground mounting. |
| Watts | 6W |
| Lumens | 223 Lumens |
| Efficacy | 37 lm/W |
| Color Temp |
2700K (Soft White) |
| Color Accuracy | 80 CRI |
| Weight | 1.6 lbs |
| Voltage | 12V AC |
| Driver |
Type:
Constant Current
|
| System Transformer |
No driver needed. Multi-tap magnetic transformer with 60 Hz only (sold separately). 054A. |
| Minimum Starting Temperature | -34°F (-30°C) |
| Lifespan |
100,000 Hours (Based on IES LM-80 results and TM-21 calculations) |
| Emits No UV Light | Yes |
| Dimmable | No |
| Wet Location Rated | Yes |
| IP66 Rating | Yes |
| UL Listed |
Yes Suitable for wet locations. Suitable for mounting within 4 feet of the ground. |
| RoHS Compliant | Yes |
| Mercury Free | Yes |
| Warranty | 5 Year |
| UPC | 019813516509 |
Dimensions
Spec Sheet:
LFLED6LVYYVG Spec Sheet
Instructions:
Installation Instructions
