17 Watts
2,100 Lumens
3500K
(Neutral White)
82 CRI
Not Dimmable
Operating Temp
-4°F to 113°F
Direct AC Capable
(Ballast Not Required)
5 Year Warranty
Product Features
Ballast Bypass
Reduces maintenance costs.
High Efficacy
Provides same output as fluorescent, but uses far less energy.
Rotatable Base
Adjust lighting direction.
DLC Listed
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities.
DLC Product Code: PSNCMEPC.
NSF Listed
Meets NSF/ANSI standards for use in Food Zone (non-contact), Splash, and Non-Food Zones.
Tube guard required in open fixtures.
Specifications
| Product Type | Compact |
| Lamp Shape | PLL |
| Lamp Base | 2G11 |
| Installation Type | Type B, Ballast Bypass |
| Installation Orientation | Horizontal |
| Finish | Frosted |
| Equivalent | 40W Fluorescent |
| Watts | 17W |
| Lumens | 2,100 Lumens |
| Efficacy | 123.5 lm/W |
| Color Temp |
3500K (Neutral White) |
| Color Accuracy | 82 CRI |
| Weight | 0.6 lbs |
| Input Voltage | 120-277V AC |
| Operating Frequency | 50 / 60 Hz |
| Power Factor | 0.9 |
| THDi | <20% |
| Operating Temperature |
-4 to 113°F -20 to 45°C |
| L70 Lifespan | 50,000 Hours |
| Dimmable | No |
| Enclosed Fixture Rated | Yes |
| For Use Outdoors in Open Fixtures | No |
| For Use in Emergency Fixtures | No |
| DLC Listed |
Yes DLC Product Code: PSNCMEPC |
| NSF Approved | Yes |
| UL Classified | Yes |
| UL Recognized | Yes |
| Mercury Free | Yes |
| CEC Status | Lawful for sale in California |
| Warranty | 5 Year |
| UPC | 019813751603 |
Dimensions
Spec Sheet:
PLL-17-835-BYP Spec Sheet
Instructions:
PLL-17-835-BYP Installation Instructions
