RAB 3.5W 2700K On Ballast or Direct Wire G23 PLS LED

Product Description

Rab 3.5 watt 2700K dual mode (on ballast or direct wire) horizontal orientation PLS LED lamp with a 2-pin G23 base.



Product Features

Ballast or Direct AC Compatible (Type A or B)

Type A/B hybrid is both ballast bypass and ballast compatible.

Damp Location Rated

Suitable for damp locations.

Environmentally Friendly

Mercury and UV free. RoHS-compliant components.

Enclosed Fixture Rated

May be used in both enclosed and open fixtures.

80 CRI

Ideal for general lighting applications.



Specifications

Product Type	Compacts
Lamp Shape	PLS-Horizontal
Lamp Base	G23 (2-Pin)
Installation Type	Type A: Ballast Compatible with Magnetic Ballasts Type B: Direct AC Compatible (Dual Mode)
Ballasting Requirements	Ballast or Direct AC Compatible
Installation Orientation	Horizontal
Technology	LED
Housing Material	Polycarbonate
Finish	White
Lens Finish	Frosted
Equivalent	7W/9W G23 CFL
Watts	3.5W
Lumens	325 Lumens
Efficacy	93 Lm/W
Color Temp	2700K (Soft White)
Color Accuracy	80 CRI
Beam Angle	120°
Weight	0.1 lbs
Input Voltage	Type A: Dependent on the ballast Type B: 120-277V AC
Operating Frequency	Type A: Dependent on the ballast Type B: 50/60 Hz
Driver	Type: Constant Current 120V: 30mA 277V: 13mA
Power Factor	>0.9
THD	20%
Operating Temperature	-4 to 113°F -20 to 45°C
L70 Lifespan	50,000 Hours (Based on IES LM-80 results and TM-21 calculations)
Emits No UV Light	Yes
Dimmable	No
Damp Location Rated	Yes
Enclosed Fixture Rated	Yes
UL Listed	Yes
UL Classified	Yes
FCC Compliant	Yes (Part 15)
RoHS Compliant	Yes
Mercury Free	Yes
Warranty	5 Year
UPC	019813916484

Dimensions

Spec Sheet: PLS-3.5-H-827-HYB Spec Sheet

Instructions: Installation Instructions

Compatibility: Compatibility List
