RAB 17W 3000K Vertical Ballast Compatible PLT LED

Product Description

RAB 17 watt 3000K ballast compatible (Type A) PLT LED with a G24q (4-pin) base.



Product Features

Ballast Compatible (Type A)

Directly Compatible with Most Existing CFL Ballasts.

Works in G24q & GX24q Bases

Compatible with 4-pin CFL installations with G24q or GX24q bases.

Damp Location Rated

Suitable for damp locations.

Environmentally Friendly

Mercury and UV free.
RoHS-compliant components.

Enclosed Fixture Rated

May be used in both enclosed and open fixtures.

DLC Listed

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities.
Designed to meet DLC 5.1 requirements.
DLC Product Code: PLFCDRGI7IQB.



Specifications

Brand Name	RAB
Product Type	Compact
Lamp Shape	PLT-Vertical
Lamp Base	G24q (4-Pin)
Installation Type	UL Type A: Ballast Compatible (Type A)
Ballasting Requirements	Ballast Required
Installation Orientation	Vertical
Technology	LED
Housing Material	Polycarbonate endcap with aluminum heatsink and glass envelop
Finish	White
Lens Finish	Frosted
Equivalent	42W G24q & Gx24q CFL
Watts	17W
Lumens	2,000 Lumens
Efficacy	117.6 Lm/W
Color Temp	3000K (Warm White)
Color Accuracy	80 CRI
Weight	0.7 lbs
Input Voltage	120-277V AC
Operating Frequency	Ballast Dependent
Driver	Type: Constant Current 120V: Ballast Dependent 277V: Ballast Dependent
Power Factor	>0.9
THD	<20%
Operating Temperature	Ballast Dependent
L70 Lifespan	50,000 Hours LED lifespan based on IES LM-70 results
Emits No UV Light	Yes
Dimmable	No
Damp Location Rated	Yes
Enclosed Fixture Rated	Yes
Certification Model Number	T10217(PLT-17-V-830-DIR)
DLC Listed	Yes Designed to meet DLC 5.1 requirements. DLC Product Code: PLFCDRGI7IQB
UL Listed	Yes
FCC Compliant	Yes (Part 15B)
RoHS Compliant	Yes
Mercury Free	Yes
Warranty	5 Year No-Compromise
UPC	019813918075

Dimensions

Spec Sheet: PLT-17-V-830-DIR Spec Sheet

Compatibility:
Ballast Compatibility List
Dimmer Compatibility List
