Direct AC Compatible
(Ballast Not Required)
54 Watts
10,000 Lumens
5000K
(Daylight)
80+ CRI
Emits no UV light
Wet Locations
IP65 Rated
Wet Locations
Dimmable
360° Beam
Operating Temp
-13°F to 113°F
Mogul Extended Base
5 Year Warranty
Product Description
RAB 54 watt 5000K direct 120-277 volt AC compatible (Type B) high lumen ED32 filament LED light bulb with an extended mogul base.
Product Features
Direct AC Compatible (Type B)
Integral driver enables lamp to be wired directly to line voltage without need for an external driver or ballast.
Omnidirectional Output
Full glass design provides omnidirectional output.
IP65 Rating
Ingress Protection rating of IP65 for dust and water.
Wet Location Rated
Suitable for wet locations.
Environmentally Friendly
Mercury and UV free. RoHS-compliant components.
Consistent Fixture-to-Fixture LED Color
7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.
Enclosed Fixture Rated
May be used in both enclosed and open fixtures in dry, damp, or wet locations.
Specifications
| Product Type | Filament HID Replacement |
| Lamp Shape | ED32 |
| Lamp Base | Mogul Extended (EX39) |
| Installation Type |
UL Type B: Direct AC Compatible (Type B - No Ballast) |
| Ballasting Requirements | No Ballast - Wire 120-277V AC Direct Only |
| Installation Orientation | Vertical |
| Technology | LED Filament |
| Housing Material | Glass |
| Lens Finish | Clear |
| Lamp Base Material | Nickel-Copper |
| Compatible Products |
Surge Protector: SP10KV Step Down Transformer 480V to 277V: XFMR200-480-277 |
| Equivalent | 300W MH (Metal-Halide) |
| Watts | 54W |
| Lumens | 10,000 Lumens |
| Efficacy | 185 Lm/W |
| Color Temp |
5000K (Daylight) |
| Color Accuracy | ≥80 CRI |
| CRI R9 | High color performance with R9 no less than 0 |
| Beam Angle | 360° |
| Diameter | 4" |
| Weight | 0.6 lbs |
| Input Voltage | 120-277V AC |
| Operating Frequency | 60 Hz |
| Input Current |
120V - 460mA 208V - 270mA 277V - 220mA |
| Power Factor | ≥0.9 |
| THD | <25% |
| Surge Protection | 4kV |
| Operating Temperature |
-13 to 113°F -25 to 45°C |
| L70 Lifespan |
50,000 Hours LED lifespan based on IES LM-70 results |
| Emits No UV Light | Yes |
| Dimmable | Yes |
| Dimming Type | TRIAC/ELV |
| Damp Location Rated | Yes |
| Wet Location Rated | Yes |
| Environment | Suitable for use in dry, damp, and wet environments. |
| Enclosed Fixture Rated | Yes |
| Energy Star Approved |
No No Energy Star category for this lamp to qualify under |
| DLC Listed | No |
| IP65 Rating | Yes |
| UL Listed | Yes |
| UL Classified | Yes |
| FCC Compliant | Yes (Part 15B) |
| RoHS Compliant | Yes |
| Mercury Free | Yes |
| California Status | Lawful for Sales in California |
| California Title 20 | Not Compliant |
| California Title 24 | Not Compliant |
| Warranty | 5 Year |
| UPC | 192552029322 |
Dimensions
Spec Sheet:
ED32-54-EX39-850-F-C Spec Sheet
Instructions:
Installation Instructions
