Direct AC Compatible
(Ballast Not Required)
27 / 36 / 45 Watts
3,645 - 3,915 Lumens
(At 27 Watts)
4,860 - 5,220 Lumens
(At 36 Watts)
6,075 - 6,525 Lumens
(At 45 Watts)
3000K/4000K/5000K
80+ CRI
Emits no UV light
Damp Locations
IP64 Rated
Damp Locations
Dimmable
(Via Optional Accessory Only)
360° Beam
Operating Temp
-22°F to 140°F
Medium Base
5 Year Warranty
Product Description
RAB selectable wattage (27/36/45 Watt) and selectable color temperature (3000K/4000K/5000K) dimmable ballast by-pass post top LED HID replacement with a medium base.
Product Features
HID Replacement
Replaces traditional metal halide or high pressure sodium HID lamps.
Direct AC Compatible (Type B)
Integral driver enables lamp to be wired directly to line voltage without need for an external driver or ballast.
Integrated Sensor Port - 5-Pin
Add the Lightcloud Blue 5-pin plug-in controller with optional sensor to connect to the Lightcloud Blue Bluetooth mesh wireless network lighting control system.
Selectable Wattage & Color Temperature
Field adjustable wattage and color temperature allows for flexibility both during and after installation.
IP64 Rating
Ingress Protection rating of IP64 for water and dust resistant.
Damp Location Rated
Suitable for damp locations.
Environmentally Friendly
Mercury and UV free. RoHS-compliant components.
Consistent Fixture-to-Fixture LED Color
6-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.
Enclosed Fixture Rated
May be used in both enclosed and open fixtures.
Specifications
| Product Type | HID Replacement |
| Lamp Shape | Post top (sensor) |
| Lamp Base | Medium (E26) |
| Installation Type |
UL Type B: Direct AC Compatible (Type B - No Ballast) |
| Ballasting Requirements | No Ballast - Wire 100-277V AC Direct Only |
| Installation Orientation | Vertical and Horizontal |
| Technology | LED |
| Sensor | 5-Pin Sensor Port |
| Housing Material | Polycarbonate |
| Finish | Clear |
| Lamp Base Material | Metal |
| Equivalent | 125W/150W/175W Metal Halide |
| Watts | 27 / 36 / 45W |
| Lumen Output |
27W: 3000K: 3,645 Lumens 4000K: 3,915 Lumens 5000K: 3,780 Lumens 36W: 3000K: 4,860 Lumens 4000K: 5,220 Lumens 5000K: 5,040 Lumens 45W: 3000K: 6,075 Lumens 4000K: 6,525 Lumens 5000K: 6,300 Lumens |
| Efficacy |
27W / 36W / 45W: 3000K: 135 Lm/W 4000K: 145 Lm/W 5000K: 140 Lm/W |
| Color Temp |
Adjustable 3000K / 4000K / 5000K |
| Color Accuracy | ≥80 CRI |
| Beam Angle | 360° |
| CRI R9 | High color performance with R9 no less than 0 |
| Bare Lamp Illuminated Length | 5-1/16" |
| Length | 9-1/16" |
| Diameter | 3-3/8" |
| Weight | 1.9 lbs |
| Input Voltage | 100-277V AC |
| Operating Frequency | 50/60 Hz |
| Driver |
Type:
Constant Current
120V:
387 mA
208V:
230 mA
240V:
203 mA
277V:
162 mA
|
| Power Factor | ≥0.9 |
| THD | ≤20% |
| Flicker | <30% |
| Surge Protection | 4kV |
| Operating Temperature |
-22 to 140°F -30 to 60°C |
| L70 Lifespan |
50,000 Hours LED lifespan based on IES LM-70 results |
| Emits No UV Light | Yes |
| Dimmable |
Yes, via the Lightcloud Blue mobile app only. Do not use with a standard dimmer or dimming control. |
| Damp Location Rated | Yes |
| Enclosed Fixture Rated | Yes |
| IP64 Rating | Yes |
| UL Listed | Yes |
| UL Classified | Yes |
| FCC | Complies with Part 15B of the FCC Rules |
| RoHS Compliant | Yes |
| Mercury Free | Yes |
| California Status | Lawful for Sales in California |
| Warranty | 5 Year |
| UPC | 192552026956 |
Dimensions
Spec Sheet:
HIDFA-45S-E26-8CCT-BYP/5SP Spec Sheet
Instructions:
Installation Instructions
