RAB 12/18/27 Watt Selectable CCT Dimmable Post Top LED

Product Description

Rab selectable wattage (12/18/27 Watt) and selectable color temperature (3000K/4000K/5000K) dimmable ballast by-pass post top LED HID replacement with a medium base.



Product Features

HID Replacement

Replaces traditional metal halide or high pressure sodium HID lamps.

Direct AC Compatible (Type B)

Integral driver enables lamp to be wired directly to line voltage without need for an external driver or ballast.

Selectable Wattage & Color Temperature

Field adjustable wattage and color temperature allows for flexibility both during and after installation.

Damp Location Rated

Suitable for damp locations.

Enclosed Fixture Rated

May be used in both enclosed and open fixtures.



Specifications

Product Type	HID Replacement
Lamp Shape	Post top
Lamp Base	Medium (E26)
Installation Type	UL Type B: Direct AC Compatible (Type B - No Ballast)
Ballasting Requirements	No Ballast - Wire 100-277V AC Direct Only
Installation Orientation	Vertical and Horizontal
Technology	LED
Sensor	No Sensor
Housing Material	Polycarbonate
Lamp Base Material	Metal
Finish	White
Equivalent	50W/75W/125W MH (Metal-Halide) 50W/75W/125W HPS (High-Pressure Sodium)
Watts	12 / 18 / 27W
Lumens	1,740 / 2,610 / 3,915 Lumens
Efficacy	145 Lm/W
Color Temp	Adjustable 3000K / 4000K / 5000K
Color Accuracy	87 CRI
Beam Angle	360°
Bare Lamp Illuminated Length	3-3/8"
Length	6-7/8"
Diameter	2-5/16"
Weight	0.8 lbs
Input Voltage	100-277V AC
Operating Frequency	50/60 Hz
Power Factor	>0.9
THD	<20%
Flicker	<30%
Operating Temperature	-22 to 140°F -30 to 60°C
L70 Lifespan	50,000 Hours LED lifespan based on IES LM-70 results
Dimmable	Yes
Damp Location Rated	Yes
Enclosed Fixture Rated	Yes
UL Listed	Yes Suitable for damp locations
UL Classified	Yes
FCC Compliant	Yes (Part 15)
RoHS Compliant	Yes
Mercury Free	Yes
Warranty	5 Year
UPC	192552004985

Dimensions

Spec Sheet: HIDFA-27S-E26-8CCT-BYP Spec Sheet

Instructions: Installation Instructions
