26 Watts
1,950 - 2,200 Lumens
2700K/3000K/3500K
4000K/5000K
90+ CRI
Emits no UV light
Wet Locations
Dimmable
(TRIAC/ELV Compatible)
Operating Temp
-4°F to 104°F
120V AC
5 Year Warranty
Product Description
Rab SUMO 15" 26 watt selectable color temperature (2700K/3000K/3500K/4000K/5000K) dimmable LED slim round surface mount fixture with a white finish.
Product Features
Smooth Diffused Light
Frosted polycarbonate lens diffuses light evenly and smoothly.
Selectable Color Temperature
Select from 5 field-adjustable color temperatures 5000K, 4000K, 3500K, 3000K, or 2700K.
Wet Location Rated
Suitable for wet locations.
Environmentally Friendly
Mercury and UV free. RoHS-compliant components.
Consistent Fixture-to-Fixture LED Color
4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.
IESNA LM-79 & LM-80 Testing
This luminaire has been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
90 CRI
Produces rich and vibrant colors.
Specifications
| Brand Name | RAB |
| Fixture Type | Edge-lit Surface Mount LED Fixture |
| Fixture Shape | Round |
| Technology | LED |
| Housing Material | Metal |
| Lens Material | Polycarbonate |
| Trim | Smooth |
| Mounting | Surface Mount |
| UV Protection | Fade-resistant powder spray polyester |
| Size | 15" |
| Equivalent | 150W Incandescent |
| Watts | 26W |
| Lumens |
2700K: 1,950 Lumens 3000K: 2,050 Lumens 3500K: 2,150 Lumens 4000K: 2,200 Lumens 5000K: 2,200 Lumens |
| Efficacy |
2700K: 75 Lm/W 3000K: 78 Lm/W 3500K: 83 Lm/W 4000K: 85 Lm/W 5000K: 85 Lm/W |
| Color Temp |
Adjustable 2700K / 3000K / 3500K / 4000K / 5000K |
| Color Accuracy | >90 CRI |
| CRI R9 |
R9 greater than or equal to 50 (High color performance) |
| Diameter | 15" |
| Height | 1-7/16" |
| Weight | 3.4 lbs |
| Input Voltage | 120V AC |
| Operating Frequency | 50/60 Hz |
| Driver |
Type:
Constant Current
120V:
0.24A
|
| Power Factor | ≥0.9 |
| THD | ≤20% |
| Surge Protection | 2.5kV |
| Operating Temperature |
-4 to 104°F -20 to 40°C |
| L70 Lifespan |
50,000 Hours LED lifespan based on IES LM-70 results |
| Emits No UV Light | Yes |
| Dimmable |
Yes - TRIAC/ELV Dims down to 10%. See Dimmer Compatibility List. |
| Wet Location Rated | Yes |
| For Use Indoors | Yes |
| For Use Outdoors | Yes |
| Energy Star Approved | Energy Star Version 2.2 Certified |
| UL Listed | Yes |
| NEC Compliant |
Suitable for use in closets. (NEC Sections 410.16 (A)(1) & 410.16 (C3)) |
| FCC Compliant | Yes (Part 15B) |
| RoHS Compliant | Yes |
| Mercury Free | Yes |
| California Status | Lawful for Sale in California |
| California Title 24 | Yes |
| Warranty | 5 Year |
| Country of Origin | Cambodia |
| Trade Agreements Act Compliant | Yes |
| UPC | 192552024679 |
Dimensions
Spec Sheet:
SUMO-R-15 Spec Sheet
Instructions:
Installation Instructions
Compatibility:
Dimmer Compatibility List
Downlight Accessory Compatibility List
