7.5 Watts
650 Lumens
2700K/3000K/3500K
4000K/5000K
90 CRI
Wet Locations
Dimmable
(TRIAC Compatible)
Operating Temp
-4°F to 104°F
Medium Base
120V AC
5 Year Warranty
Product Description
Rab PUCK 5" 7.5 watt selectable color temperature (2700K/3000K/3500K/4000K/5000K) dimmable slim round disk LED flush mount fixture with a white finish.
Product Features
Installation Options
Slim wafer design fits in a 4" recessed can or 4" J-box.
Compatible with 4" metal octagon or 4" plastic J-boxes with minimum of 3.2" clearance.
Selectable Color Temperature
Field adjustable color temperature options from 2700/3000/3500/4000/5000K.
Easy Trim Replacement
Steel trim with magnetic design for quick trim replacement.
Trim color options available in brushed nickel, black, and bronze.
Socket Adapter Included
Includes E26 cap as an accessory to meet T24 & T20 requirements.
Dimmable
Compatible with TRIAC dimming systems.
Wet Location Rated
Suitable for wet locations.
90 CRI
Produces rich and vibrant colors.
Specifications
| Fixture Type | Recessed Downlights |
| Fixture Shape | Round |
| Lamp Base | Medium (E26) |
| Technology | LED |
| Material | Metal |
| Finish | White |
| Trim | Smooth Trim |
| Mounting | Surface and Recessed Mounting |
| Watts | 7.5W |
| Lumens | 650 Lumens |
| Efficacy | 87 Lm/W |
| Color Temp |
Adjustable 2700K / 3000K / 3500K / 4000K / 5000K |
| Color Accuracy | 90 CRI |
| CRI R9 |
R9 greater than or equal to 50 (High color performance) |
| Diameter | 5" |
| Height | 1-1/4" |
| Weight | 0.5 lbs |
| Input Voltage | 120V AC |
| Operating Frequency | 60 Hz |
| Driver |
Type:
Constant Current
120V:
0.07A
|
| Dimming Driver |
TRIAC Compatible Dimming as low as 10%. |
| Power Factor | ≥0.9 |
| THD | ≤20% |
| Flicker | ≤30% |
| Operating Temperature |
-4 to 104°F -20 to 40°C |
| L70 Lifespan |
50,000 Hours LED lifespan based on IES LM-70 results |
| Dimmable | Yes - TRIAC |
| Damp Location Rated | Yes |
| Wet Location Rated | Yes |
| Energy Star Approved | Energy Star Version 2.2 Certified |
| UL Listed |
Yes Suitable for wet locations |
| FCC Compliant | Yes (Part 15) |
| RoHS Compliant | Yes |
| California Status | Lawful for sale in California |
| California Title 20 | Yes |
| California Title 24 | Yes |
| Warranty | 5 Year |
| UPC | 192552014588 |
Dimensions
Spec Sheet:
PUCKFA-4R-7.5-9CCT-120-WS Spec Sheet
Instructions:
Installation Instructions
Compatibility:
Dimmer Compatibility List
