RAB SUMO 9" 18W 2700K-5000K Dimmable Round LED Edge-lit Surface Mount Fixture

Product Description

RAB SUMO 9" 18 watt selectable color temperature (2700K/3000K/3500K/4000K/5000K) dimmable LED round edge-lit surface mount fixture with a white finish.



Product Features

Smooth And Even Light Distribution

Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications.

Selectable Color Temperature

Select from 5 field-adjustable color temperatures 2700K, 3000K, 3500K, 4000K, or 5000K.

Wet Location Rated

Suitable for wet locations.

Environmentally Friendly

Mercury and UV free. RoHS-compliant components.

Consistent Fixture-to-Fixture LED Color

4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.

IESNA LM-79 & LM-80 Testing

This luminaire has been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

90 CRI

Produces rich and vibrant colors.



Specifications

Brand Name	RAB
Product Family	SUMO
Fixture Type	Edge-lit Surface Mount
Fixture Shape	Round
Technology	LED
Enclosure Material	Metal
Finish	White
Trim	Smooth
Accessories	SM-9R-W/EMBB Emergency battery backup driver (field installed) SM-9R-CASE EXTENDER FOR 9" SUMO
Mounting	Surface mount
Equivalent	75W Incandescent
Watts	18W
Lumens	2700K: 1,182 Lumens 3000K: 1,221 Lumens 3500K: 1,278 Lumens 4000K: 1,305 Lumens 5000K: 1,299 Lumens
Efficacy	2700K: 68 Lm/W 3000K: 70 Lm/W 3500K: 73 Lm/W 4000K: 75 Lm/W 5000K: 74 Lm/W
Color Temp	Adjustable 2700K / 3000K / 3500K / 4000K / 5000K
Color Accuracy	>90 CRI
CRI R9	R9 greater than or equal to 50 (High color performance)
Beam Angle	110°
Fixture Size	9"
Weight	1.5 lbs
Input Voltage	120V AC
Operating Frequency	60 Hz
Driver	Type: Constant Current, Class 2 120V: 167mA
Power Factor	≥0.9
Flicker	≤30%
Operating Temperature	-4 to 104°F -20 to 40°C
L70 Lifespan	50,000 Hours LED lifespan based on IES LM-70 results
Emits No UV Light	Yes
Dimmable	Yes - TRIAC/ELV Dims down to 10%. See Dimmer Compatibility List.
Wet Location Rated	Yes
Certification Model Number	DAS0002(DAISYKIT6)
Energy Star Approved	Energy Star Version 2.2 Certified
UL Listed	Yes
NEC Compliant	Suitable for use in closets. (NEC Sections 410.16 (A)(1) & 410.16 (C1))
IC Rated	No
Air Tight	No
FCC Compliant	Yes (Part 15)
RoHS Compliant	Yes
Mercury Free	Yes
California Status	Lawful for Sale in California
California Title 20	No
California Title 24	Conforms with California Title 24 Part 6
California Title 24	Yes
Warranty	5 Year
Country of Origin	Cambodia
Trade Agreements Act Compliant	Yes
UPC	192552028868

Dimensions

Spec Sheet: SUMO-R-9 Spec Sheet

Instructions: Installation Instructions

Compatibility:
Dimmer Compatibility List
Downlight Accessory Compatibility List
