RAB 12"x12" 20W 2700K-5000K LED Surface Mount Fixture

Product Description

RAB 12" X 12" 20 watt selectable color temperature (2700K/3000K/3500K/4000K/5000K) square frame edge-lit LED surface mount fixture with white finish.



Product Features

Selectable Color Temperature

Select from 5 field-adjustable color temperatures 2700K, 3000K, 3500K, 4000K, or 5000K.

Dimmable

Compatible with TRIAC dimming systems.

Damp Location Rated

Suitable for damp locations.

90 CRI

Produces rich and vibrant colors.



Specifications

Fixture Type	Edge-lit Surface Mount LED Fixture
Fixture Shape	Square
Technology	LED
Material	Metal
Finish	White
Trim	Smooth Trim
Mounting	Surface mount
Equivalent	40W CFL
Watts	20W
Lumens	2700K: 1,700 Lumens 3000K: 1,750 Lumens 3500K: 1,800 Lumens 4000K: 1,850 Lumens 5000K: 1,850 Lumens
Efficacy	2700K: 85 Lm/W 3000K: 88 Lm/W 3500K: 90 Lm/W 4000K: 93 Lm/W 5000K: 93 Lm/W
Color Temp	Adjustable 2700K / 3000K / 3500K / 4000K / 5000K
Color Accuracy	90 CRI
Length	11-5/8"
Width	11-5/8"
Height	15/16"
Weight	2 lbs
Input Voltage	120-277V AC
Operating Frequency	50/60 Hz
Driver	Type: Constant Current 120V: 0.19A 208V: 0.12A 240V: 0.11A 277V: 0.09A
Power Factor	≥0.9
THD	≤30%
Operating Temperature	-4 to 104°F -20 to 40°C
L70 Lifespan	50,000 Hours LED lifespan based on IES LM-70 results
Dimmable	Yes - TRIAC See Dimmer Compatibility List
Damp Location Rated	Yes
For Use Indoors	Yes
Energy Star Approved	Energy Star Version 2.2 Certified Energy Star ID: 2396875
IC Rated	Yes Suitable for direct contact with insulation
California Status	Lawful for sale in California
California Title 24	Yes
Warranty	5 Year
Country of Origin	Cambodia
Trade Agreements Act Compliant	Yes
UPC	192552018678

Dimensions

Spec Sheet: SMPFA1X1S20UNVTW Spec Sheet

Instructions: Installation Instructions

Compatibility: Dimmer Compatibility List
