100 / 120 / 150 Watts
15,317 - 22,224 Lumens
3000K/4000K/5000K
83+ CRI
Emits no UV light
Wet Locations
IP65 Rated
Wet Locations
Dimmable
(0-10V Dimming Only)
Operating Temp
-40°F to 145°F
120-277V AC
5 Year Warranty
Product Description
RAB selectable wattage (100/120/150 watt) and selectable color temperature (3000K/4000K/5000K) 0-10V dimming 120-277 volt wet rated round LED UFO hi-bay light fixture with a white finish.
Product Features
Selectable Wattage
Power selection switch allows selecting between 150W/120W/100W (factory default 150W).
Selectable Color Temperature
Color selection switch allows selecting between 3000K, 4000K and 5000K (factory default 4000K).
Dimmable
0-10V dimming driver standard.
IP65 Rating
Ingress Protection rating of IP65 for dust and water.
Wet Location Rated
Suitable for wet locations.
Environmentally Friendly
Mercury and UV free.
RoHS-compliant components.
Consistent Fixture-to-Fixture LED Color
7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.
Mounting
Comes standard with a hanging hook and a 6-foot cord.
Capable of mounting to a pendant with a 3/4"-14 mount with additional accessory H17-PM KIT.
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities.
Designed to meet DLC 5.1 requirements.
DLC Product Code: S-AXTFS7.
IESNA LM-79 & LM-80 Testing
This luminaire has been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
Specifications
| Brand Name | RAB |
| Fixture Type | UFO Hi-Bay |
| Fixture Shape | Round |
| Technology | LED |
| Housing Material | Precision die-cast aluminum |
| Finish | White |
| Reflector | Polycarbonate and Aluminum |
| Lens | Polycarbonate lens |
| Equivalent | 400W MH (Metal-Halide) |
| Watts | 100 / 120 / 150W |
| Lumens | 15,317 - 22,224 Lumens |
| Efficacy | 140.1 - 168.8 Lm/W |
| Color Temp |
Adjustable 3000K / 4000K / 5000K |
| Color Accuracy | 83-86 CRI |
| Height | 7-7/16" |
| Diameter | 10-5/16" |
| Weight | 4.7 lbs |
| Voltage | 120-277V AC |
| Operating Frequency | 50/60 Hz |
| Driver |
Type:
Constant Current
100W:
120V: 0.86A, 208V: 0.50A, 240V: 0.43A, 277V: 0.37A
120W:
120V: 1.03A, 208V: 0.59A, 240V: 0.51A, 277V: 0.44A
150W:
120V: 1.24A, 208V: 0.72A, 240V: 0.62A, 277V: 0.54A
|
| Dimming Driver |
Driver includes wiring for 0-10V dimming systems. Dim as low as 10%. |
| Power Factor |
120V: 99.71% 277V: 93.05% |
| THD |
120V: 3.25% 277V: 5.6% |
| Surge Protection |
L-N: 4 kV L/N-PE: 6 kV |
| Operating Temperature |
Max Power Temp Rating: -40 to 122°F (-40 to 50°C) Middle Power Temp Rating: -40 to 135°F (-40 to 57°C) Low Power Temp Rating: -40 to 145°F (-40 to 63°C) |
| L70 Lifespan | 100,000 Hours |
| Emits No UV Light | Yes |
| Dimmable | Yes (0-10V Dimming Only) |
| Wet Location Rated | Yes |
| Certification Model Number | H17-002 |
| DLC Listed |
DLC Premium Designed to meet DLC 5.1 requirements. DLC Product Code: S-AXTFS7 |
| IP65 Rating | Yes |
| UL Listed |
Yes Suitable for wet locations |
| RoHS Compliant | Yes |
| Mercury Free | Yes |
| Limited Warranty |
5 Year Limited Covers light output, driver performance and paint finish. |
| UPC | 192552022026 |
Dimensions
Spec Sheet:
H17 Spec Sheet
Instructions:
Installation Instructions
