150 / 200 / 240 Watts
22,696 - 37,253 Lumens
3000K/4000K/5000K
82+ CRI
Emits no UV light
Wet Locations
IP65 Rated
Wet Locations
Dimmable
(0-10V Dimming Only)
Operating Temp
-40°F to 149°F
120-277V AC
5 Year Warranty
Product Description
RAB selectable wattage (150/200/240 watt) and selectable color temperature (3000K/4000K/5000K) 0-10V dimming 120-277 volt wet rated round LED UFO hi-bay light fixture with a white finish.
Product Features
Selectable Wattage
Power selection switch allows selecting between 240W/200W/150W (factory default 240W).
Selectable Color Temperature
Color selection switch allows selecting between 3000K, 4000K and 5000K (factory default 4000K).
Dimmable
0-10V dimming driver standard.
IP65 Rating
Ingress Protection rating of IP65 for dust and water.
Wet Location Rated
Suitable for wet locations.
Environmentally Friendly
Mercury and UV free.
RoHS-compliant components.
Consistent Fixture-to-Fixture LED Color
7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.
Mounting
Comes standard with a hanging hook and a 6-foot cord.
Capable of mounting to a pendant with a 3/4"-14 mount with additional accessory H17-PM KIT.
DLC Listed
This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities.
Designed to meet DLC 5.1 requirements.
DLC Product Code: S-LED17S.
IESNA LM-79 & LM-80 Testing
This luminaire has been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
Specifications
| Brand Name | RAB |
| Fixture Type | UFO Hi-Bay |
| Fixture Shape | Round |
| Technology | LED |
| Housing Material | Precision die-cast aluminum |
| Finish | White |
| Reflector | Polycarbonate and Aluminum |
| Lens | Polycarbonate lens |
| Equivalent | 750W MH (Metal-Halide) |
| Watts | 150 / 200 / 240W |
| Lumens | 22,696 - 37,253 Lumens |
| Efficacy | 135.6 - 168.4 Lm/W |
| Color Temp |
Adjustable 3000K / 4000K / 5000K |
| Color Accuracy | 82-86 CRI |
| Height | 7-7/8" |
| Diameter | 12-5/8" |
| Weight | 7 lbs |
| Voltage | 120-277V AC |
| Operating Frequency | 50/60 Hz |
| Driver |
Type:
Constant Current
150W:
120V: 1.25A, 208V: 0.72A, 240V: 0.63A, 277V: 0.54A
200W:
120V: 1.69A, 208V: 0.98A, 240V: 0.85A, 277V: 0.73A
240W:
120V: 2.01A, 208V: 1.16A, 240V: 1.00A, 277V: 0.87A
|
| Dimming Driver |
Driver includes wiring for 0-10V dimming systems. Dim as low as 10%. |
| Power Factor |
120V: 99.78% 277V: 93.12% |
| THD |
120V: 4.89% 277V: 9.64% |
| Surge Protection |
L-N: 4 kV L/N-PE: 6 kV |
| Operating Temperature |
Max Power Temp Rating: -40 to 122°F (-40 to 50°C) Middle Power Temp Rating: -40 to 135°F (-40 to 57°C) Low Power Temp Rating: -40 to 149°F (-40 to 65°C) |
| L70 Lifespan | 100,000 Hours |
| Emits No UV Light | Yes |
| Dimmable | Yes (0-10V Dimming Only) |
| Wet Location Rated | Yes |
| Certification Model Number | H17XL-002 |
| DLC Listed |
DLC Premium Designed to meet DLC 5.1 requirements. DLC Product Code: S-LED17S |
| IP65 Rating | Yes |
| UL Listed |
Yes Suitable for wet locations |
| RoHS Compliant | Yes |
| Mercury Free | Yes |
| Limited Warranty |
5 Year Limited Covers light output, driver performance and paint finish. |
| UPC | 192552022033 |
Dimensions
Spec Sheet:
H17XL Spec Sheet
Instructions:
Installation Instructions
