RAB 4" 7W 5CCT Downlight LED Retrofit with Smooth Trim

Product Description

RAB 4" 7 watt 5CCT adjustable color round recessed downlight LED retrofit with medium base adapter and smooth trim.



Product Features

Smooth And Even Light Distribution

Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications.

Selectable Color Temperature

Color selection switch allows selecting between 2700/3000/3500/4000/5000K.

Compatible with Recessed Housings

Compatible with most standard recessed housings.

Socket Adapter Included

Medium Base (E26) Socket adapter included.

Indoor & Outdoor Use

Anti-UV plastic extends the life of the housing.

Dimmable

Dimmable down to 10% on triac dimmers.

Dimmable

Compatible with TRIAC dimming systems.

Wet Location Rated

Suitable for wet locations.

Consistent Fixture-to-Fixture LED Color

4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.

IESNA LM-79 & LM-80 Testing

This luminaire has been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

90 CRI

Produces rich and vibrant colors.



Specifications

Fixture Type	Recessed Retrofit
Fixture Shape	Round
Lamp Base	Medium (E26)
Cut Out Template Size	4 5/16"
Technology	LED
Enclosure Material	Plastic
Trim	Smooth
Accessories	4" Brushed nickel trim round baffle: DLTRIM/R4RB-BN-L 4" Bronze trim round baffle: DLTRIM/R4RB-BRZ-L 4" Black trim round baffle: DLTRIM/R4RB-B-L 4" New construction housing: NDCANIC4R 4" Retrofit housing: RDCANIC4R Emergency driver 25W: DRI-25-EMGR-DC Emergency driver 21W 0-10V T20: DRI-21-EMGR-DC-D10
Certification Model Number	DLR0141(R34-4)
Mounting	Recessed Housing
UV Rated	Suitable for exposure to direct sunlight
Equivalent	60W Incandescent
Watts	7.5W
Lumens	2700K: 739 Lumens 3000K: 751 Lumens 3500K: 754 Lumens 4000K: 733 Lumens 5000K: 725 Lumens
Efficacy	2700K: 99 Lm/W 3000K: 100 Lm/W 3500K: 101 Lm/W 4000K: 98 Lm/W 5000K: 97 Lm/W
Color Temp	Adjustable 2700K / 3000K / 3500K / 4000K / 5000K
Color Accuracy	>90 CRI
CRI R9	R9 greater than or equal to 50 (High color performance)
Beam Angle	90°
Recessed Can Size	4"
Height	1-1/2"
Diameter	5-5/16"
Weight	0.2 lbs
Input Voltage	120V AC
Operating Frequency	60 Hz
Driver	Type: Constant Current 120V: 80mA
Power Factor	≥0.7
Flicker	≤30%
Operating Temperature	-13 to 104°F -25 to 40°C
L70 Lifespan	50,000 Hours LED lifespan based on IES LM-70 results
Dimmable	Yes - TRIAC/ELV Dims down to 10%. See Dimmer Compatibility List.
Wet Location Rated	Yes
Listings	UL Classified
Energy Star Approved	Energy Star Version 2.2 Certified Energy Star ID: 2669160
NEC Compliant	Suitable for use in closets. (NEC Sections 410.16 (A)(1) & 410.16 (C3))
IC Rated	No
Air Tight	No
FCC Compliant	Yes (Part 15)
RoHS Compliant	Mercury and UV free. RoHS-compliant components.
California Status	Lawful for Sales in California
California Title 20	Yes
California Title 24	No
Warranty	5 Year
UPC	192552031141

Dimensions

Spec Sheet: R34-4 Spec Sheet

Instructions: Installation Instructions

Compatibility:
Dimmer Compatibility
Downlight Accessory Compatibility List
