10 Watts
1,000 Lumens
2700K/3000K/3500K
4000K/5000K
90+ CRI
Emits no UV light
Wet Locations
Dimmable
(TRIAC/ELV Compatible)
120V AC
5 Year Warranty
Product Description
RAB 4" round 8 watt selectable color temperature (2700K/3000K/3500K/4000K/5000K) recessed retrofit LED downlight with E26 adapter and baffle trim.
Product Features
Smooth And Even Light Distribution
Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications.
Selectable Color Temperature
Color selection switch allows selecting between 2700K, 3000K, 3500K, 4000K, & 5000K.
Compatible with Recessed Housings
Compatible with most standard recessed housings.
Dimmable
TRIAC/ELV dims down to 10%. See Dimmer Compatibility List.
Dent & Scratch Resistant
Wet Location Rated
Suitable for wet locations.
Environmentally Friendly
Mercury and UV free. RoHS-compliant components.
Consistent Fixture-to-Fixture LED Color
4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.
IESNA LM-79 & LM-80 Testing
This luminaire has been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
90 CRI
Produces rich and vibrant colors.
Specifications
| Fixture Type | Recessed Retrofit |
| Fixture Shape | Round |
| Recessed Can Size | 4" |
| Cut Out Template Size | 4 5/16" |
| Technology | LED |
| Enclosure Material | Metal |
| Finish | White |
| Trim | Baffle |
| Mounting | Recessed |
| Equivalent | 75W Incandescent |
| Watts | 10W |
| Lumens | 1,000 Lumens |
| Efficacy | 100 Lm/W |
| Color Temp |
Adjustable 2700K / 3000K / 3500K / 4000K / 5000K |
| Color Accuracy | >90 CRI |
| Height | 2-13/16" |
| Diameter | 5-5/16 |
| CRI R9 |
R9 greater than or equal to 50 (High color performance) |
| Weight | 0.6 lbs |
| Input Voltage | 120V AC |
| Operating Frequency | 60 Hz |
| Driver |
Type:
Constant Current
120V:
0.91A
|
| Power Factor | ≥0.9 |
| THD | ≤20% |
| Flicker | ≤30% |
| L70 Lifespan |
50,000 Hours LED lifespan based on IES LM-70 results |
| Emits No UV Light | Yes |
| Dimmable |
Yes - TRIAC/ELV Dims down to 10%. See Dimmer Compatibility List. |
| Damp Location Rated | Yes |
| Wet Location Rated | Yes |
| Safety Listing | UL Recognized, UL Classified |
| Energy Star Approved |
Energy Star Version 2.2 Certified Energy Star ID: 2401348 |
| DLC Listed |
No. No Design Lights Consortium category for this product to qualify under |
| NEC Compliant |
Suitable for use in closets. (NEC Sections 410.16 (A)(1) & 410.16 (C3)) |
| IC Rated | No |
| Air Tight | No |
| FCC | Complies with Part 15B of the FCC Rules |
| RoHS Compliant | Yes |
| Mercury Free | Yes |
| California Status | Lawful for Sales in California |
| California Title 20 | Yes |
| California Title 24 | Conforms with California Title 24 Part 6 |
| Warranty | 5 Year |
| UPC | 192552024655 |
Dimensions
Spec Sheet:
R4R109FA120WB Spec Sheet
Instructions:
Installation Instructions
Compatibility:
Dimmer Compatibility List
