6 Watts
1,750 Center Beam
Candlepower
367 - 436 Lumens
2700K/3000K/3500K
4000K/5000K
90+ CRI
Emits no UV light
Wet Locations
Dimmable
(TRIAC/ELV Compatible)
20° Beam
Operating Temp
-13°F to 104°F
Insulation Contact
Rated
(Except Spray Foam)
Air Tight
120V AC
5 Year Warranty
Product Description
RAB 2" 6 watt selectable color temperature (2700K/3000K/3500K/4000K/5000K) dimmable white smooth trim remote driver gimbal recessed LED downlight fixture with a 20° beam.
Product Features
Smooth And Even Light Distribution
Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications.
New Construction or Retrofit Applications
The remote driver makes this fixture ideal for new construction and retrofit applications.
Wet Location Rated
Suitable for wet locations.
Environmentally Friendly
Mercury and UV free. RoHS-compliant components.
Consistent Fixture-to-Fixture LED Color
4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.
Mounting
Includes spring loaded retention clips for secure installation.
IESNA LM-79 & LM-80 Testing
This luminaire has been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
90 CRI
Produces rich and vibrant colors.
Installation
No recessed housing or j-box required.
Specifications
| Fixture Type | Recessed Gimbal Downlight |
| Fixture Shape | Round |
| Technology | LED |
| Enclosure Material | Metal |
| Finish | White |
| Trim | Smooth |
| Certification Model Number | DLG0011(G2NB) |
| Mounting | Recessed, no housing required |
| Tilt | 30° |
| Equivalent | 50W Incandescent |
| Watts | 6W |
| Lumens |
2700K: 367 Lumens 3000K: 405 Lumens 3500K: 427 Lumens 4000K: 436 Lumens 5000K: 427 Lumens |
| Efficacy |
2700K: 61 Lm/W 3000K: 69 Lm/W 4000K: 75 Lm/W 5000K: 71 Lm/W |
| Center Beam Candlepower | 1,750 |
| Color Temp |
Adjustable 2700K / 3000K / 3500K / 4000K / 5000K |
| Color Accuracy | >90 CRI |
| CRI R9 |
R9 greater than or equal to 50 (High color performance) |
| Beam Angle | 20° |
| Fixture Size | 2" |
| Weight | 0.5 lbs |
| Input Voltage | 120V AC |
| Operating Frequency | 60 Hz |
| Driver |
Type:
Constant Current, Class 2
120V:
50mA
|
| Power Factor | ≥0.9 |
| THD | ≤25% |
| Flicker | ≤30% |
| Operating Temperature |
-13 to 104°F -25 to 40°C |
| L70 Lifespan |
50,000 Hours LED lifespan based on IES LM-70 results |
| Emits No UV Light | Yes |
| Dimmable |
Yes, dims down to 10% on compatible TRIAC/ELV systems. See Dimmer Compatibility List. |
| Damp Location Rated | Yes |
| Wet Location Rated | Yes |
| Listings | ETL Listed |
| Energy Star Approved |
Energy Star Version 2.2 Certified Energy Star ID: 2571827 |
| cULus Listed | cULus Listed - Damp Location Rated |
| NEC Compliant |
Suitable for use in closets. (NEC Sections 410.16 (A)(1) & 410.16 (C3)) |
| IC Rated |
Yes Suitable for direct contact with insulation. (Not for use in direct contact with spray foam insulation, consult NEMA LSD57-2013) |
| Air Tight | Housing certified Air Tight as per ASTM E283 |
| FCC Compliant | Yes (Part 15B) |
| RoHS Compliant | Yes |
| Mercury Free | Yes |
| California Status | Lawful for Sales in California |
| California Title 20 | No, this product does not meet California Title 20 requirements. |
| California Title 24 | Conforms with California Title 24 Part 6 |
| Warranty | 5 Year |
| UPC | 192552029131 |
Dimensions
Spec Sheet:
G2NB Spec Sheet
Instructions:
CutOut Template
Installation Instructions
Compatibility:
Dimmer Compatibility
Downlight Accessory Compatibility List
