RAB 3" 15W 38° Beam Baffle Recessed Remote Driver LED Downlight

Product Description

RAB 3" 15 watt selectable color temperature (2700K/3000K/3500K/4000K/5000K) dimmable white baffle trim remote driver recessed LED downlight fixture with a 38° beam.



Product Features

Smooth And Even Light Distribution

Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications.

New Construction or Retrofit Applications

The remote driver makes this fixture ideal for new construction and retrofit applications.

Wet Location Rated

Suitable for wet locations.

Environmentally Friendly

Mercury and UV free. RoHS-compliant components.

Consistent Fixture-to-Fixture LED Color

4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.

Mounting

Includes spring loaded retention clips for secure installation.

IESNA LM-79 & LM-80 Testing

This luminaire has been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

90 CRI

Produces rich and vibrant colors.

Installation

No recessed housing or j-box required.



Specifications

Fixture Type	Recessed Downlights
Fixture Shape	Round
Technology	LED
Enclosure Material	Metal
Finish	White
Trim	Baffle
Certification Model Number	DLR0136(R3-15B)
Mounting	Recessed, no housing required
Equivalent	125W Incandescent
Watts	15W
Lumens	2700K: 958 Lumens 3000K: 1,037 Lumens 3500K: 1,112 Lumens 4000K: 1,144 Lumens 5000K: 1,136 Lumens
Efficacy	2700K: 67 Lm/W 3000K: 74 Lm/W 4000K: 83 Lm/W 5000K: 79 Lm/W
Center Beam Candlepower	2,270
Color Temp	Adjustable 2700K / 3000K / 3500K / 4000K / 5000K
Color Accuracy	>90 CRI
CRI R9	R9 greater than or equal to 50 (High color performance)
Beam Angle	38°
Fixture Size	3"
Weight	1 lbs
Input Voltage	120V AC
Operating Frequency	60 Hz
Driver	Type: Constant Current, Class 2 120V: 125mA
Power Factor	≥0.9
THD	≤25%
Flicker	≤30%
Operating Temperature	-13 to 104°F -25 to 40°C
L70 Lifespan	50,000 Hours LED lifespan based on IES LM-70 results
Emits No UV Light	Yes
Dimmable	Yes, dims down to 10% on compatible TRIAC/ELV systems. See Dimmer Compatibility List.
Damp Location Rated	Yes
Wet Location Rated	Yes
Listings	ETL Listed
Energy Star Approved	Energy Star Version 2.2 Certified Energy Star ID: 2571992
cULus Listed	cULus Listed - Damp Location Rated
NEC Compliant	Suitable for use in closets. (NEC Sections 410.16 (A)(1) & 410.16 (C3))
IC Rated	Yes Suitable for direct contact with insulation. (Not for use in direct contact with spray foam insulation, consult NEMA LSD57-2013)
Air Tight	Housing certified Air Tight as per ASTM E283
FCC Compliant	Yes (Part 15B)
RoHS Compliant	Yes
Mercury Free	Yes
California Status	Lawful for Sales in California
California Title 20	No, this product does not meet California Title 20 requirements.
California Title 24	Conforms with California Title 24 Part 6
Warranty	5 Year
UPC	192552029070

Dimensions

Spec Sheet: R3-15B Spec Sheet

Instructions:
CutOut Template
Installation Instructions

Compatibility:
Dimmer Compatibility
Downlight Accessory Compatibility List
