RAB 4" 8W Downlight LED Daisy Chain Wafer with Baffle Trim

Product Description

RAB 4" 8 watt 5CCT adjustable color round recessed downlight LED daisy chain wafer with a baffle trim.



Product Features

Linkable

Power multiple wafers with a single driver (4" up to 10 pcs.).

Smooth And Even Light Distribution

Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications.

New Construction or Retrofit Applications

Wet Location Rated

Suitable for wet locations.

Environmentally Friendly

Mercury and UV free. RoHS-compliant components.

Consistent Fixture-to-Fixture LED Color

4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.

IESNA LM-79 & LM-80 Testing

This luminaire has been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

90 CRI

Produces rich and vibrant colors.

Installation

No recessed housing or j-box required.



Specifications

Fixture Type	Daisy Wafer
Fixture Shape	Round
Cut Out Template Size	4 5/16"
Technology	LED
Enclosure Material	Polycarbonate
Finish	White
Trim	Baffle
Accessories	50' Extension cord with connectors: DAISY50
Certification Model Number	DAS0007(DAISY4B)
Mounting	Recessed Housing
Equivalent	60W Incandescent
Watts	8W
Lumens	660 Lumens
Efficacy	69 Lm/W
Color Temp	Adjustable 2700K / 3000K / 3500K / 4000K / 5000K
Color Accuracy	>90 CRI
CRI R9	R9 greater than or equal to 50 (High color performance)
Size	4"
Weight	0.5 lbs
Input Voltage	120-277V AC
Operating Frequency	60 Hz
Driver	Type: Constant Current, Class 2 120V: 95mA 208V: 92mA 240V: 93mA 277V: 93mA
Dimming Driver	Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 5%.
Power Factor	≥0.9
Flicker	≤30%
Operating Temperature	-13 to 104°F -25 to 40°C
L70 Lifespan	50,000 Hours LED lifespan based on IES LM-70 results
Emits No UV Light	Yes
Dimmable	Yes, 0-10V dims down to 5%. See Dimmer Compatibility List.
Damp Location Rated	Yes
Wet Location Rated	Yes
Energy Star Approved	No
cULus Listed	cULus Listed - Damp Location Rated
UL Listed	Yes
NEC Compliant	Suitable for use in closets. (NEC Sections 410.16 (A)(1) & 410.16 (C3))
IC Rated	Yes Suitable for direct contact with insulation. (Not for use in direct contact with spray foam insulation, consult NEMA LSD57-2013)
Air Tight	Housing certified Air Tight as per ASTM E283
FCC Compliant	Yes (Part 15B)
RoHS Compliant	Yes
Mercury Free	Yes
California Status	Lawful for Sales in California
California Title 20	Not applicable
California Title 24	Not applicable
Warranty	5 Year
Country of Origin	Cambodia
Trade Agreements Act Compliant	Yes
UPC	192552028592

Dimensions

Spec Sheet: DAISY4B Spec Sheet

Instructions: Installation Instructions

Compatibility: Downlight Accessory Compatibility List
