54 Watts
3,912 Lumens
2700K/3000K/3500K
4000K/5000K
90+ CRI
Emits no UV light
Wet Locations
Dimmable
(0-10V Dimming Only)
Operating Temp
-13°F to 104°F
Insulation Contact
Rated
(Except Spray Foam)
Air Tight
120-277V AC
5 Year Warranty
Product Description
RAB kit (6 fixtures) 4" 8 watt 5CCT adjustable color round recessed downlights LED daisy chain wafers with a smooth trim.
Product Features
Linkable
Power multiple wafers with a single driver (4" up to 10 pcs.).
Smooth And Even Light Distribution
Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications.
New Construction or Retrofit Applications
Wet Location Rated
Suitable for wet locations.
Environmentally Friendly
Mercury and UV free. RoHS-compliant components.
Consistent Fixture-to-Fixture LED Color
4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.
IESNA LM-79 & LM-80 Testing
This luminaire has been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
90 CRI
Produces rich and vibrant colors.
Installation
No recessed housing or j-box required.
Specifications
| Fixture Type | Daisy Wafer Kit |
| Fixtures in Kit | 6 |
| Fixture Shape | Round |
| Cut Out Template Size | 4 5/16" |
| Technology | LED |
| Enclosure Material | Polycarbonate |
| Finish | White |
| Trim | Smooth |
| Accessories |
50' Extension Cord with Connectors: DAISY50 4" Daisy Wafer (Smooth Trim): DAISY4 4" Daisy Wafer (Baffle Trim): DAISY4B 6" Daisy Wafer (Smooth Trim): DAISY6 6" Daisy Wafer (Baffle Trim): DAISY6B |
| Certification Model Number | DAS0001(DAISYKIT4) |
| Kit Includes |
(1) 120-277V, 0-10V Dimmable Driver (6) Edge-lit CCT Field Adjustable Wafers |
| Mounting | Recessed Housing |
| Equivalent | (6) 60W Incandescent |
| Watts | 54W |
| Lumens | 3,912 Lumens |
| Efficacy | 72 Lm/W |
| Color Temp |
Adjustable 2700K / 3000K / 3500K / 4000K / 5000K |
| Color Accuracy | >90 CRI |
| CRI R9 |
R9 greater than or equal to 50 (High color performance) |
| Fixture Size | 4" |
| Weight | 6.6 lbs |
| Input Voltage | 120-277V AC |
| Operating Frequency | 60 Hz |
| Driver |
Type:
Constant Current, Class 2
120V:
457mA
208V:
277mA
240V:
248mA
277V:
226mA
|
| Dimming Driver |
Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 5%. |
| Power Factor | ≥0.9 |
| THD | 20% |
| Flicker | ≤30% |
| Operating Temperature |
-13 to 104°F -25 to 40°C |
| L70 Lifespan |
50,000 Hours LED lifespan based on IES LM-70 results |
| Emits No UV Light | Yes |
| Dimmable | Yes, 0-10V dims down to 5%. See Dimmer Compatibility List. |
| Damp Location Rated | Yes |
| Wet Location Rated | Yes |
| Energy Star Approved |
Energy Star Version 2.2 Certified Energy Star ID: 2448355 |
| cULus Listed | cULus Listed - Damp Location Rated |
| UL Listed | Yes |
| NEC Compliant |
Suitable for use in closets. (NEC Sections 410.16 (A)(1) & 410.16 (C3)) |
| IC Rated |
Yes Suitable for direct contact with insulation. (Not for use in direct contact with spray foam insulation, consult NEMA LSD57-2013) |
| Air Tight | Housing certified Air Tight as per ASTM E283 |
| FCC Compliant | Yes (Part 15B) |
| RoHS Compliant | Yes |
| Mercury Free | Yes |
| California Status | Lawful for Sales in California |
| California Title 20 | Not applicable |
| California Title 24 | Conforms with California Title 24 Part 6 |
| Warranty | 5 Year |
| Country of Origin | Cambodia |
| Trade Agreements Act Compliant | Yes |
| UPC | 192552028530 |
Dimensions
Spec Sheet:
DAISYKIT4 Spec Sheet
Instructions:
Installation Instructions
Compatibility:
Downlight Accessory Compatibility List
