15 Watts
1,270 - 1,378 Lumens
2700K/3000K/3500K
4000K/5000K
90+ CRI
Emits no UV light
Wet Locations
2 Hour
Fire Resistant
Dimmable
(TRIAC/ELV Compatible)
90° Beam
Operating Temp
-4°F to 104°F
Insulation Contact
Rated
Air Tight
120V AC
5 Year Warranty
Product Description
RAB 6" 15 watt selectable color temperature (2700K/3000K/3500K/4000K/5000K) dimmable white smooth trim remote driver fire resistant recessed LED downlight fixture.
Product Features
Smooth And Even Light Distribution
Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications.
Selectable Color Temperature
Recessed CCT selectable dipswitch.
New Construction or Retrofit Applications
Wet Location Rated
Suitable for wet locations.
Environmentally Friendly
Mercury and UV free. RoHS-compliant components.
Consistent Fixture-to-Fixture LED Color
4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.
Simple and Quick Installation
Can be installed in ceilings from 3/8" to 5/8" thick with spring-loaded retention clips.
No recessed housing or j-box required.
Cutout template included in box.
Easy Maintenance
Can be removed from below the ceiling for service or replacement.
90 CRI
Produces rich and vibrant colors.
Remote Driver / Junction Box
Die formed metal driver / junction box with captive hinged junction box cover.
Listed for (6) #12 AWG 90°C splice conductors (2-in, 2-out & 2-ground).
(4) 1/2" conduit pry-outs.
(3) quick snap-in connectors for line voltage connections.
Specifications
| Fixture Type | Edge-Lit Wafer |
| Fixture Shape | Round |
| Cut Out Template Size | 4 5/16" |
| Technology | LED |
| Enclosure Material | Metal |
| Finish | White and Red |
| Trim | Smooth |
| Accessories |
6' Extension Cable: EXTCBL-FA-6 12' Extension Cable: EXTCBL-FA-12 20' Extension Cable: EXTCBL-FA-20 |
| Certification Model Number | DLW0097(FWAFER6) |
| Mounting | Recessed Housing |
| Type | Constant Current, Class 2 |
| Equivalent | 75W Halogen |
| Watts | 15W |
| Lumen Output |
2700K: 1,270 Lumens 3000K: 1,313 Lumens 3500K: 1,364 Lumens 4000K: 1,378 Lumens 5000K: 1,327 Lumens |
| Efficacy |
2700K: 85 Lm/W 3000K: 88 Lm/W 3500K: 91 Lm/W 4000K: 92 Lm/W 5000K: 88 Lm/W |
| Color Temp |
Adjustable 2700K / 3000K / 3500K / 4000K / 5000K |
| Color Accuracy | >90 CRI |
| CRI R9 |
R9 greater than or equal to 50 (High color performance) |
| Beam Angle | 90° |
| Size | 6" |
| Weight | 1.4 lbs |
| Input Voltage | 120V AC |
| Operating Frequency | 60 Hz |
| Driver |
Type:
Constant Current, Class 2
120V:
137mA
|
| Power Factor | ≥0.9 |
| THD | ≤20% |
| Flicker | 5% |
| Operating Temperature |
-4 to 104°F -20 to 40°C |
| L70 Lifespan |
50,000 Hours LED lifespan based on IES LM-70 results |
| Emits No UV Light | Yes |
| Dimmable |
Yes, using compatible TRIAC/ELV dimming systems. Dimmable down to 10%. |
| Wet Location Rated | Yes |
| For Use Indoors | Yes |
| For Use Outdoors | Yes |
| Fire Resistant | Tested to UL 263 standards for 2-hour fire resistance |
| Energy Star Approved | Energy Star Version 2.2 Certified |
| DLC Listed | Not applicable |
| IC Rated | Suitable for direct contact with insulation |
| Air Tight | Housing certified Air Tight as per ASTM E283 |
| FCC Compliant | Yes (Part 15B) |
| RoHS Compliant | Yes |
| Mercury Free | Yes |
| California Status | Lawful for Sales in California |
| California Title 20 | Not applicable |
| California Title 24 | Conforms with California Title 24 Part 6 |
| Warranty | 5 Year |
| Country of Origin | Cambodia |
| Trade Agreements Act Compliant | Yes |
| UPC | 192552030038 |
Dimensions
