18 Watts
1,600 - 1,800 Lumens
2700K/3000K/3500K
4000K/5000K
90 CRI
Wet Locations
Dimmable
45° Beam
Operating Temp
-4°F to 104°F
Insulation Contact
Rated
(Except Spray Foam)
Air Tight
120V AC
5 Year Warranty
Product Description
RAB 6" 18 watt selectable color temperature (2700K/3000K/3500K/4000K/5000K) dimmable white round remote driver recessed LED downlight fixture for HALED.
NOTE: This component must be ordered with the 6" HALED trim in order to make a complete fixture.
Product Features
Uniform Light Distribution
45-degree optical lens provides uniform light distribution.
Color Trim Options
Separate snap-in color trims available in round, square, smooth and baffle for in-field installation.
Wet Location Rated
Suitable for wet locations.
90 CRI
Produces rich and vibrant colors.
Specifications
| Fixture Type | Recessed Downlights |
| Fixture Shape | Round |
| Technology | LED |
| Material | Metal |
| Trim | Sold Separately |
| Expose to UV Light | Yes |
| Mounting | Recessed ceiling |
| Watts | 18W |
| Lumens | 1,600 - 1,800 Lumens |
| Efficacy | 89 - 100 Lm/W |
| Color Temp |
Adjustable 2700K / 3000K / 3500K / 4000K / 5000K |
| Color Accuracy | 90 CRI |
| Beam Angle | 45° |
| Width | 4-3/4" |
| Height | 2-1/2" |
| Weight | 1.2 lbs |
| Input Voltage | 120V AC |
| Operating Frequency | 60 Hz |
| Driver |
Type:
Constant Current
120V:
0.17A
|
| Power Factor | 0.9 |
| THD | ≤20% |
| Operating Temperature |
-4 to 104°F -20 to 40°C |
| L70 Lifespan |
50,000 Hours LED lifespan based on IES LM-70 results |
| Dimmable |
Yes See Dimmer Compatibility List |
| Damp Location Rated | Yes |
| Wet Location Rated | Yes |
| Energy Star Approved | Energy Star Version 2.2 Certified |
| cULus Listed | cULus Listed - Damp Location Rated |
| UL Listed |
Yes Suitable for wet locations |
| IC Rated |
Yes Suitable for direct contact with insulation. (Not for use in direct contact with spray foam insulation, consult NEMA LSD57-2013) |
| Air Tight | Yes, per ASTM-E283-04 |
| FCC Compliant | Yes (Part 15B) |
| California Status | Lawful for sale in California |
| California Title 24 | Conforms with California Title 24 Part 6 |
| Warranty | 5 Year |
| Country of Origin | Cambodia |
| Trade Agreements Act Compliant | Yes |
| UPC | 192552024747 |
Dimensions
Spec Sheet:
HA6 Spec Sheet
Instructions:
Cut Out Template
Installation Instructions
Compatibility:
Dimmer Compatibility List
Downlight Accessory Compatibility List
