15 Watts
1,525 - 1,685 Lumens
2700K/3000K/3500K
4000K/5000K
90+ CRI
Emits no UV light
Wet Locations
Dimmable
(TRIAC/ELV Compatible)
90° Beam
Operating Temp
-4°F to 104°F
Insulation Contact
Rated
(Except Spray Foam)
Air Tight
120-277V AC
5 Year Warranty
Product Description
RAB 6" 15 watt selectable color temperature (2700K/3000K/3500K/4000K/5000K) dimmable white baffle trim remote driver deep regress wafer recessed LED downlight fixture.
Product Features
Smooth And Even Light Distribution
Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications.
Wet Location Rated
Suitable for wet locations.
Environmentally Friendly
Mercury and UV free. RoHS-compliant components.
Consistent Fixture-to-Fixture LED Color
4-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.
IESNA LM-79 & LM-80 Testing
This luminaire has been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
90 CRI
Produces rich and vibrant colors.
Installation
No recessed housing or j-box required.
Specifications
| Fixture Type | Deep Regress Wafer |
| Fixture Shape | Round |
| Cut Out Template Size | 6 5/16" |
| Technology | LED |
| Enclosure Material | Metal |
| Finish | White |
| Trim | Baffle |
| Accessories |
Mounting Plate w/nailer bar: DLPLATE/WFR3468/NB Mounting plate for 3", 4", 5" and 6": DLPLATE/WFR3456 |
| Certification Model Number | DLW0103(WFD6B) |
| Mounting | Recessed, no housing required |
| Equivalent | 120W Incandescent |
| Watts | 15W |
| Lumens |
2700K: 1,525 Lumens 3000K: 1,562 Lumens 3500K: 1,627 Lumens 4000K: 1,662 Lumens 5000K: 1,685 Lumens |
| Efficacy |
2700K: 108 Lm/W 3000K: 112 Lm/W 3500K: 118 Lm/W 4000K: 119 Lm/W 5000K: 118 Lm/W |
| Color Temp |
Adjustable 2700K / 3000K / 3500K / 4000K / 5000K |
| Color Accuracy | >90 CRI |
| CRI R9 |
R9 greater than or equal to 50 (High color performance) |
| Beam Angle | 90° |
| Fixture Size | 6" |
| Weight | 0.8 lbs |
| Input Voltage | 120-277V AC |
| Operating Frequency | 60 Hz |
| Driver |
Type:
Constant Current, Class 2
120V:
137mA
|
| Power Factor | ≥0.9 |
| THD | ≤20% |
| Flicker | 5% |
| Operating Temperature |
-4 to 104°F -20 to 40°C |
| L70 Lifespan |
50,000 Hours LED lifespan based on IES LM-70 results |
| Emits No UV Light | Yes |
| Dimmable |
Yes, dims down to 10% on compatible TRIAC/ELV systems. See Dimmer Compatibility List. |
| Damp Location Rated | Yes |
| Wet Location Rated | Yes |
| For Use Indoors | Yes |
| For Use Outdoors | Yes |
| Energy Star Approved |
Energy Star Version 2.2 Certified Energy Star ID: 2508118 |
| cULus Listed | cULus Listed - Damp Location Rated |
| UL Listed | Yes |
| NEC Compliant |
Suitable for use in closets. (NEC Sections 410.16 (A)(1) & 410.16 (C3)) |
| IC Rated |
Yes Suitable for direct contact with insulation. (Not for use in direct contact with spray foam insulation, consult NEMA LSD57-2013) |
| Air Tight | Housing certified Air Tight as per ASTM E283 |
| FCC Compliant | Yes (Part 15) |
| RoHS Compliant | Yes |
| Mercury Free | Yes |
| California Status | Lawful for Sales in California |
| California Title 20 | No, this product does not meet California Title 20 requirements. |
| California Title 24 | Conforms with California Title 24 Part 6 |
| Warranty | 5 Year |
| Country of Origin | Cambodia |
| Trade Agreements Act Compliant | Yes |
| UPC | 192552029223 |
Dimensions
